HCR-1510
2
SERVICE INFORMATION
1 SERVICE INFORMATION
1-1 Specifications
Model HCR-1510
Dimensions Length mm(in) 990 (39.0)
Width mm(in) 250 (9.8)
Height mm(in) 195 (7.7)
Dry weight kg(lb) 5.2 (11.5)
Engine Type KIORITZ, air-cooled, two-stroke, single cylinder
Rotation Anticlockwise as viewed from the output end
Displacement cm
3
(in
3
) 21.2 (1.29)
Bore mm(in) 32.2 (1.27)
Stroke mm(in) 26.0 (1.02)
Compression ratio 6.1
Carburettor Type Diaphragm, horizontal-draught, with primer (purge bulb)
Model ZAMA C1U-K54A
Ignition Type CDI (Capacitor discharge ignition) system
Variable Slope Timing (VST) : Slope advance ignition
system combined with electronic speed governor
Spark plug BPMR-7A
Starter Type Automatic rewind
Rope diameter x length mm(in) 3.0 x 890 (0.12 x 35.0)
Fuel Type Premixed two-stroke fuel
Mixture ratio 50 : 1 (2 %)
Petrol Minimum 89 octane petrol (RON)
Two-stroke air cooled engine oil ISO-L-EGD (ISO/CD13738), JASO FC
Tank capacity L (U.S.fl.oz.) 0.3 (10.1)
Clutch Type Centrifugal, 2-shoe slide
Handle Type Front Plastic grip with hand guard
Rear Integrated control plastic grip
Gear case Reduction ratio 4.5
Gear tooth Spur gear
Lubrication Lithium based grease
(Grease up every 15-20 hours of operating)
Cutter Type Double reciprocating double edge blade
Called length mm(in) 580 (23)
Pitch mm(in) 35 (1.38)
Height mm(in) 21 (0.83)
Thickness mm(in) 2.5 (0.098)
Lubrication Drop a few oil every 4 hours of operation to 4 bolt slots
