PAS-280 SPECIFICATIONS
© 1/2014 ECHO Inc.
X7502312904 27
SPECIFICATIONS
MODEL PAS-280
Length 1028 mm (40.5 in.)
Width 254 mm (10.0 in.)
Height 257 mm (10.12 in.)
Weight (dry) 4.8 kg (10.6 lb.)
Engine Type Air cooled, two-stroke, single cylinder gasoline engine
Bore 34.0 mm (1.34 in.)
Stroke 31.0 mm (1.22 in.)
Displacement 28.1 cc (1.71 cu. in.)
Exhaust Spark arrestor muffler or spark arrestor muffler with catalyst
Carburetor Diaphragm w/purge pump
Ignition System Flywheel magneto, capacitor discharge ignition type
Spark Plug NGK BPM-8Y (Gap 0.65 mm (0.026 in.)
Fuel Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio
50 : 1 Power Blend X
TM
ISO-L-EGD (ISO/CD 13738) and J.A.S.O. M345- FD, two-stroke,
air-cooled engine oil.
Gasoline
Use 89 Octane unleaded. Do not use fuel containing methyl alcohol, more than 10% ethyl
alcohol or 15% MTBE. Do not use alternative fuels such as E-15 or E-85.
Oil Power Blend X
TM
Premium Universal 2-Stroke Oil
Fuel Tank Capacity 0.62 lit. (21.1 US fl. oz.)
Starter System Automatic Rewind Starter
Clutch Centrifugal Type
Drive Shaft 6.35 mm (1/4 in.) flexible shaft
Idle Speed 2,800 RPM
Clutch Engagement Speed 3,750 RPM
Wide Open Throttle Speed (W.O.T.) 9,750 RPM
