OPERATION PB-250LN
22 X7501186001
© 2/2016 ECHO Inc.
5. Recoil Starter
Place the unit on a flat, clear area.
Firmly grasp throttle handle with
left hand and rapidly pull recoil
starter handle/rope (E) until
engine fires, or maximum 5 pulls.
6. Choke
Move choke lever (C) to RUN
position, and if necessary, restart
engine.
Note: If engine does not start with choke in RUN position after 5 pulls,
repeat instructions 3 - 6.
7. Throttle Trigger
After engine warm up, gradually depress throttle trigger to increase engine
RPM to operating speed.
Note: Allow engine to warm up 3 minutes before use.
Starting Warm Engine
The starting procedure is the same as
Cold Start except DO NOT close the
choke.
1. Stop Switch
Move stop switch (A) away from the
STOP position.
2. Throttle Position Lever
Move throttle position lever (B)
midway between idle and full throttle
positions.
3. Purge Bulb
Pump purge bulb (D) until fuel is
visible and flows freely in the
clear fuel tank return line.
