Echo PB-9010 H User Manual

PB-9010 H/T MAINTENANCE
X7501200700 41
© 08/20 ECHO Incorporated
Clear Debris
1. Brush accumulated debris from
intake grill and other cooling
passages.
Cleaning Cylinder Fins
1. Disconnect spark plug lead
from spark plug.
2. Remove engine cover.
3. Clean cylinder fins (A) to allow
cooling air to pass freely.
4. Install engine cover.
5. Connect spark plug lead.
Exhaust System
Spark Arrestor Screen
Level 2.
Carbon deposits in muffler will cause a drop in engine output and
overheating. Spark arrestor screen must be checked periodically.
Parts Required: Spark Arrestor Screen
A
A

Echo PB-9010 H Specifications

General

Engine Displacement	79.9 cc
Air Volume	1110 CFM
Air Speed	220 MPH
Type	Backpack Blower
Air Volume at Nozzle	1110 CFM
Max Air Speed	220 MPH
Fuel Capacity	83.8 fl. oz.
Fuel Tank Capacity	83.8 fl. oz.
