MAINTENANCE PB-9010 H/T
44 X7501200700
© 08/20 ECHO Incorporated
If the engine is adjusted for operation above 1,100 feet (335 m)
above sea level, the carburetor must be re-adjusted when operating
the engine below 1,100 ft. (335 m) above sea level, otherwise severe
engine damage may result.
Level 2.
Note: Every unit is run at the factory and the carburetor is set in
compliance with emission regulations. Carburetor
adjustments, other than idle speed, must be performed by an
authorized ECHO dealer.
Idle Adjustment
Before adjustment make sure that:
• Air filter is clean and properly installed.
• Spark arrestor screen and muffler are free of carbon.
• Blower pipes are installed.
1. Start engine, run at idle for one minute.
2. Complete warm up by running at full throttle for 5 minutes, operating
choke twice to clear air from carburetor chambers.
3. Check idle speed and reset if
necessary. If a tachometer is
available, idle speed screw (A)
should be set to the
specifications found on
“Specifications” Page of this
manual. Turn idle screw (A)
clockwise to increase idle
speed; counter clockwise to
decrease idle speed.
Parts Required: None
A
A

Echo PB-9010 H Specifications

General

Engine Displacement	79.9 cc
Air Volume	1110 CFM
Air Speed	220 MPH
Type	Backpack Blower
Air Volume at Nozzle	1110 CFM
Max Air Speed	220 MPH
Fuel Capacity	83.8 fl. oz.
Fuel Tank Capacity	83.8 fl. oz.
