POWER PRUNER
TM
OPERATOR'S MANUAL
11
HANDLE SHAFT / POWER HEAD
1. Remove protective cap from drive shaft end.
2. Loosen two (2) clamping screws (A) and remove locating screw
(B).
 3XOOÀH[LEOHGULYHVKDIWFRXSOHULQRXWRIGULYHVKDIWDVVHPEO\
 $OLJQÀH[LEOHGULYHVKDIWFRXSOHUZLWKHQJLQHVRFNHWDQGVOLGH
together until locating hole in shaft is visible through locating hole
in engine housing.
5. Install locating screw and tighten clamping bolts.
A
B
 $OLJQÀH[LEOHGULYHVKDIWFRXSOHUZLWKGULYHVKDIWVRFNHWDQGVOLGH
together until handle shaft is fully seated into drive shaft.
5. Tighten clamping bolts (A).
