19
DPAS-2100
99922205734
© 08/2021 ECHO Incorporated
• If the battery or charger is damaged, replace the battery or the
charger.
• Stop the machine and wait until the motor stops before you
install or remove the battery.
• Read and understand the instructions in the battery and charger
manual.
ASSEMBLY
1. Align the lift ribs on the battery
with the grooves in the battery
compartment.
2. Push the battery into the battery
compartment until the battery locks
into place.
3. When you hear a click, the battery
is installed.
Install the Battery
Remove the Battery
1. Push and hold the battery release button (G).
2. Remove the battery from the machine.
G
