SRM-2620U OPERATION
X7502341900 27
© 10/2016 ECHO Inc.
ENGLISH
80 Tooth Brush Blade is
designed for cutting brush and
woody growth up to 13 mm (1/
2 in.) diameter.
22 Tooth Clearing Blade is
designed for dense thickets
and saplings up to 64 mm (2-
1/2 in.) diameter.
Use Shoulder/Waist Harness
Use of the Shoulder/Waist
Harness is recommended for
ALL Trimmer/Brush Cutter use,
not just Blade operation. The
Shoulder/Waist Harness when
used in a trimming operation
with nylon line head suspends
the trimmer from the operator's
shoulder and reduces operator
fatigue.
During blade operation,
the same fatigue
reduction is achieved. Safety to the operator is also enhanced
by reducing the possibility of blade contact with the operator's
hands and feet by restricting trimmer movement.
Note: In case of Emergency, pull
up on the Quick Release
Collar to disconnect the
trimmer from the harness.
To Next Page
