SRM-2620U MAINTENANCE
X7502341900 35
© 10/2016 ECHO Inc.
ENGLISH
1. Close choke (COLD START [ ] position). This prevents dirt from
entering the carburetor throat when the air filter is removed. Brush
accumulated dirt from air cleaner area.
2. Remove air filter cover. Brush dirt from inside cover.
Assure throttle wire retaining clip
remains in place as shown when
removing or installing air filter cover.
3. Remove foam pre-filter and
air filter and clean as
indicated below:
Foam Pre-filter
• Clean foam filter in water/
detergent solution and
rinse with clean water.
• Wrap the filter in a clean,
dry cloth and squeeze (do
not wring) dry. Allow to
dry completely before
reuse. Do not oil.
Air Filter
• Lightly brush debris from filter. Replace filter if it is damaged, fuel
soaked, very dirty, or the rubber sealing edges are deformed.
4. Assemble components in reverse order.
