TC-210 MAINTENANCE
1. Remove throttle cable end from the
carburetor swivel.
2. Remove starter cover.
Note: The throttle cable remains
assembled to the starter
cover.
3. Disconnect spark plug lead.
4. Remove cylinder cover. (A)
5. Use brush to remove dirt from the
cylinder fins.
DO NOT use a metal scraper to
remove dirt from the cylinder fins.
6. Assemble components in reverse
order.
Note: When installing the cylinder cover, be certain the muffler gasket
tabs are locked into the muffler grill slots and the stop switch lead
is seated in the relief notch.
Exhaust System
Spark Arrestor Screen
Level 2.
Parts Required: Spark Arrestor Screen, Gasket
