MAINTENANCE TC-210
32 X7504083609
© 4/2016 ECHO Inc.
2. Start engine and run for several
minutes to reach operating
temperature.
3. Stop engine. Turn HI (A) speed
needle CCW (counter clockwise)
to stop. Turn LO (B) speed needle
midway between full CCW and CW
(clockwise) stops.
4. Idle Speed Adjustment
Start engine and turn idle speed
adjustment screw (C), CW until the
tines begin to turn, then turn the screw CCW until tines stop turning. Turn
screw CCW an additional 1/4 turn.
5. Accelerate to full throttle for 2-3 seconds to clear excess fuel from engine
then return to idle. Accelerate to full throttle to check for smooth transition
from idle to full throttle. If engine hesitates, turn LO (B) needle CCW an
additional 1/8 turn and repeat acceleration. Continue adjusting until
smooth acceleration results.
6. Check HI (A) speed RPM at W.O.T. (Wide Open Throttle). HI speed RPM
should be set to specifications found on "Specifications" page of this
manual.
7. Check idle speed and reset if necessary. If a tachometer is available, idle
speed should be set to the specification found on "Specifications" page of
this manual.
When carburetor adjustment is completed, the cutting attachment
should not move at idle, otherwise serious personal injury may
result.
Lubrication
Level 1.
Parts
Required:
Lithium Base Grease.
