WP-1000 SPECIFICATIONS
© 4/2015 ECHO Inc.
X7505120800 31
SPECIFICATIONS
MODEL WP-1000
Length 310 mm (12.2 in.)
Width 226 mm (8.9 in.)
Height 305 mm (12.0 in.)
Weight (dry) 5.4 kg (11.9 lb.)
Engine Type Air cooled, two-stroke, single cylinder gasoline engine
Bore 32.2 mm (1.27 in.)
Stroke 26.0 mm (1.02 in.)
Displacement 21.2 cc (1.29 cu. in.)
Exhaust Spark arrestor muffler or spark arrestor muffler with catalyst
Carburetor Diaphragm w/purge pump
Ignition System Flywheel magneto, capacitor discharge ignition type
Spark Plug NGK BPM-7A (Gap 0.65 mm (0.026 in.)
Fuel Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio
50 : 1 Power Blend X
TM
ISO-L-EGD (ISO/CD 13738) and J.A.S.O. M345- FD, two-stroke,
air-cooled engine oil.
Gasoline
Use 89 Octane unleaded. Do not use fuel containing methyl alcohol, more than 10% ethyl
alcohol or 15% MTBE. Do not use alternative fuels such as E-15 or E-85.
Oil Power Blend X
TM
Premium Universal 2-Stroke Oil
Fuel Tank Capacity 0.4 lit. (13.5 US fl. oz.)
Starter System Automatic Rewind Starter
Maximum Suction Lift 7.5 m (24.6 ft.)
Maximum Total Head 29 m (95.1 ft.)
Maximum Discharge 105 liters/min. (27.7 gal/min. 1662 gal/hr.)
Impeller Material Cast Iron
Volute Material Cast Iron
Seal Type Carbon Ceramic Seal
Idle Speed 2,800 RPM
Wide Open Throttle Speed (W.O.T.) 6,000 RPM
Maximum Vertical Suction Lift 7.5 mm (24 ft.)
Total Maximum Vertical Discharge Vertical Suction plus Vertical Discharge = 29 m (95 ft.)
