CARACTÉRISTIQUES TECHNIQUES
CA120
POWER (STEREO / MONO)
2x56W@4 1% THD
2x68W@4 10% THD
2x34W@8 1% THD
2x41W@8 10% THD
FREQUENCY RESPONSE
15Hz - 30kHz (-3dB)
THD+NOISE @ 1KHZ FULL POWER
SPEAKER OUT
<0.15%
THD+NOISE AUX OUT
<0.02%
CHANNEL CROSSTALK @ 1KHZ
>65Db
INPUTS SENSITIVITY NOM/IMPEDANCE
LINE1
-6dBV (0dBV*)/>8k
LINE2
-6dBV (0dBV*)/>8k
LINE3
-6dBV (0dBV*)/>8k
MICRO (BAL)
-20 to -50dBV/>1k
CMRR
MICRO (BAL)
>65dB @ 1kHz
OUTPUTS LEVEL/MINIMUM LOAD
AUX OUT
-2dBV/10k
TONE CONTROL (LINE & MIC)
BASS
100Hz ±10dB
TREBLE
6KHz ±10dB
SIGNAL NOISE RATIO
LINE
>85dB
MIC (BAL)
>65Db
TALKOVER
TIME
2 Sec**
DEPTH
-30dB**
MICROPHONE NOISE GATE
20-30 below max.**
PHANTOM VOLTAGE
+24VDC/10mA max.*
RS-232
BAUD RATE
9600 (fixed)
DATA
8 bits
PARITY
NONE
STOP BITS
1
FLOW CTRL
NONE
ANALOG REMOTE (0-10V. BASED)
Volume & Input/preset**
Selection
INFRARED REMOTE
Volume & Mute
MAINS (USING SUPPLIED DC ADAPTER)
100-240VAC 50/60Hz + External PSU 24VDC
POWER CONSUMPTION
pink noise, 1/8 power @ 4ohm
33VA/24W
pink noise, 1/3 power @ 4ohm
58VA/52W
Stand By (time 2 minutes
<2.5W
GENERAL
Dimensions WxHxD
160x210x48mm
Weight
950g
*Internally selectable **Software selectable
