13. TECHNICAL FEATURES
WARM2
Audio Performances
Inputs Sensitivity
nom/Impedance
Outputs Level/Minimum Load
Frequency Response
THD+N
CMMR
Signal Noise Ratio
Max Undistorted Output Level
LINE
PHONO
MICRO
FX RETURN
HOUSE (BAL)
HOUSE (UNBAL)
BOOTH (UNBAL)
REC
HEADPHONES
FX SEND
LINE
MICRO
PHONO
FX RETURN
LINE
MICRO
PHONO
FX RETURN
MICRO
LINE
MICRO
PHONO
FX RETURN
HOUSE (Electr.BAL)
HOUSE (UNBAL)
BOOTH (UNBAL)
0dBV/50kΩ
-40dBV/50kΩ
-50dBV/>1kΩ
0dBV/>6kΩ
0dBV/600Ω 1V *(+12dB 4V)
0dBV/2.2kΩ 1V *(+12dB 4V)
0dBV/2.2kΩ 1V *(+12dB 4V)
0dBV/10kΩ
200mΩ/200Ω THD 1%
0dBV/2.2kΩ
10Hz÷30kHz -1dB
10Hz÷25kHz -1dB
RIAA ±0.5dB
10Hz÷50kHz -1dB
<0.006%
<0.9%
<0.08%
<0.005%
>70dB @ 1kHz
>99dB
>85dB
>98dB
>100dB
21dBV (23dBu)
21dBV (23dBu)
21dBV (23dBu)
Trim control
Tone control Inputs 1-2
Tone control Input 3
Tone control Isolator
Tone Filter cut frequency at -6dB
(slope 12dB/oct)
Isolator cut frequency at -6dB
(slope 24dB/oct)
INPUTS 1-2
INPUT 3
BASS
MID
TREBLE
BASS
TREBLE
BASS
MID
TREBLE
BASS
MID
TREBLE
BASS
MID
TREBLE
± 15dB
± 20dB
+10/-30dB
+10/-25dB
+10/-30dB
± 15dB
± 15dB
+12/-70dB
+12/-40dB
+12/-70dB
200Hz
200Hz÷6.8kHz
6.8kHz
300Hz
300Hz÷4kHz
4kHz
