Check that all of the following components are present
Check that all of the following components are present
-
2
-
GPS antenna components
MAP DVD-ROM x 1
10
GPS antenna
x 1
11
Waterproof cushion
x 1
12
Ground plate
x 1
13
Body protective sheet
x 1
14
Interconnecting cable
(Rear speaker connector)
(6P) x 1
3
Interconnecting cable
4
(Speed pulse parking brake and
reverse signal connector)
(5P) x 1
Main unit x 1
1
Wiring components
Clamp
(for GPS antenna) x 3
15
Cable tie
(for GPS antenna) x 4
16
Harness fixing tape
x 2
17
When installing the main unit, some vehicle models may require the use of items that need to be
obtained separately such as a power supply adaptor cable, radio antenna adaptor cable or mounting
bracket.
Tip
Interconnecting cable
(Power and front speaker connector)
(10P) x 1
2
Main unit components
Hex-head bolt
(M5x8) x 8
7
Flathead screw
(M5x8) x 8
8
Splicing connector
x 3
9
Antenna
extension cable x 1
6
Interconnecting cable
(Video input connector)
(6P) x 1
5
