Eclipse P400 User Manual

4 5
TABLE OF CONTENTS
1. SPECIFICATIONS ................................................................................................................................................................................................................. 5
2. EXPLODED VIEW ................................................................................................................................................................................................................ 6
3. ACCESSORIES ..................................................................................................................................................................................................................... 8
4. I/O PORTS ............................................................................................................................................................................................................................. 9
5. CONNECTIONS ................................................................................................................................................................................................................... 10
6. PANEL REMOVAL ................................................................................................................................................................................................................. 11
7. MOTHERBOARD INSTALLATION ................................................................................................................................................................................... 13
8. POWER SUPPLY INSTALLATION ..................................................................................................................................................................................... 14
9. FILTERS REMOVAL .............................................................................................................................................................................................................. 15
10. FANS COMPATIBILITY ....................................................................................................................................................................................................... 16
11. HARD DRIVE INSTALLATION .......................................................................................................................................................................................... 17
12. HARD DRIVE CAGE ............................................................................................................................................................................................................ 18
13. DROP-N-LOCK SSD BRACKET ......................................................................................................................................................................................... 19
14. WATERCOOLING INSTALLATION ................................................................................................................................................................................... 20
15. OPTIONAL UPGRADES ...................................................................................................................................................................................................... 22
16. SUPPORT AND SERVICES ................................................................................................................................................................................................. 23
1. SPECIFICATIONS
CLEARANCE
Graphic card 395 mm (15.2 in)
280 mm (11.0 in) Optional HDD brackets installed
CPU cooler 170 mm (6.7 in)
Cable Management 25 mm (1.0 in)
PSU (including cable) 270 mm (10.6 in)
Warranty 5 Years*
CASE SPECIFICATIONS
Dimension 210 mm x 465 mm x 470 mm (W x H x D)
8.3 in x 18.3 in x 18.5 in
Form Factor Mid Tower
Material(s) Steel chassis, steel exterior, ABS,
Tempered Glass
Motherboard support ATX, Micro ATX, Mini ITX
E-ATX *(up to 272mm wide, unable to use
rubber grommets)
Front I/O 2x USB 3.0, Mic, Headphone, Reset,
LED Color Control, *3-Speed Fan
controller (*Eclipse P400S models only)
Side window Tempered Glass Side Panel
EXPANSION & DRIVE BAYS
Expansion slots 7
Internal 3.5” 6 (2x included)
Internal 2.5” (dedicated) 2 (2x included)
COOLING (FANS)
120 mm 140 mm
Front 3x (1x included) 2x
Top 2x 2x
Rear 1x (1x included) -
LIQUID COOLING
120 mm (Radiator) 140 mm (Radiator)
Front Up to 360* Up to 280
Top - -
Rear 120 -
* 360 radiator requires the removal of the midplate cover

Eclipse P400 Specifications

General

Type	Mid Tower
Dimensions	210mm x 465mm x 470mm
Motherboard Support	ATX, Micro-ATX, Mini-ITX
Expansion Slots	7
Cooling Support	Front: 3x 120mm or 2x 140mm, Top: 2x 120mm or 2x 140mm, Rear: 1x 120mm
Pre-installed Fans	1x 120mm Rear
Maximum GPU Length	395mm
Maximum CPU Cooler Height	160mm
Maximum PSU Length	270mm
Front Radiator Support	Up to 360mm
Rear Radiator Support	120mm
Material	Steel
Drive Bays	2 x 2.5", 2 x 3.5"
Front I/O Ports	2x USB 3.0, Audio In/Out
