pag.2
LB357 AZUR 40/60 - BLU 120 P / 120 MC BM2
CARATTERISTICHE TECNICHE DEI BRUCIATORI /CARACTERISTIQUES TECHNIQUES DES BRULEURS
MODELLO / MODELE 2° FAMIGLIA / 2° EME FAMILLE 3° FAMIGLIA / 3° EME FAMILLE
AZUR 40 G20 G25 G31 G30
Potenza termica max. kcal/h 38.700 38.700 38.700 38.700
Puissance thermique max.
kW 45 45 45 45
Potenza termica min. kcal/h 19.780 19.780 19.780 19.780
Puissance thermique min.
kW 23 23 23 23
Portata gas max. 4,51 Nm
3
/h 5,25 Nm
3
/h 3,48 kg/h 3,56 kg/h
Débit gaz
min. 2,35 Nm
3
/h 2,74 Nm
3
/h 1,78 kg/h 1,82 kg/h
Pressione nominale
mbar 20 25 37 28/30
Pression nominale
Pressione massima
mbar 25 30 45 35
Pression maximum
Pressione minima
mbar 17 20 25 25
Pression minimum
Combustibile gas P.C.I.
kcal/Nm
3
8.570 7.370 22.260 29.320
Combustible gaz P.C.I.
AZUR 60 G20 G25 G31 G30
Potenza termica max. kcal/h 61.920 61.920 61.920 61.920
Puissance thermique max.
kW 72 72 72 72
Potenza termica min. kcal/h 30.100 30.100 30.100 30.100
Puissance thermique min.
kW 35 35 35 35
Portata gas max. 7,22 Nm
3
/h 8,40 Nm
3
/h 5,57 kg/h 5,71 kg/h
Débit gaz
min. 3,51 Nm
3
/h 4,08 Nm
3
/h 2,72 kg/h 2,78 kg/h
Pressione nominale
mbar 20 25 37 28/30
Pression nominale
Pressione massima
mbar 25 30 45 35
Pression maximum
Pressione minima
mbar 17 20 25 25
Pression minimum
Combustibile gas P.C.I.
kcal/Nm
3
8.570 7.370 22.260 29.320
Combustible gaz P.C.I.
BLU 120 P/MULTICOMPACT G20 G25 G31 G30
Potenza termica max. kcal/h 100.620 100.620 100.620 100.620
Puissance thermique max.
kW 117 117 117 117
Potenza termica min. kcal/h 51.600 51.600 51.600 51.600
Puissance thermique min.
kW 60 60 60 60
Portata gas max. 11,74 Nm
3
/h 13,65 Nm
3
/h 9,09 kg/h 9,28 kg/h
Débit gaz
min. 6,24 Nm
3
/h 7,25 Nm
3
/h 4,66 kg/h 4,76 kg/h
Pressione nominale
mbar 20 25 37 28/30
Pression nominale
Pressione massima
mbar 25 30 45 35
Pression maximum
Pressione minima
mbar 17 20 25 25
Pression minimum
Combustibile gas P.C.I.
kcal/Nm
3
8.570 7.370 22.260 29.320
Combustible gaz P.C.I.
TECHNICAL DATA /TECHNISCHE DATEN DER BRENNER
MODEL / MODELL 2ND FAMILY / 2. FAMILIE 2ND FAMILY / 2. FAMILIE
AZUR 40 G20 G25 G31 G30
Thermal power max. kcal/h 38.700 38.700 38.700 38.700
max. Wärmeleistung
kW 45 45 45 45
Thermal power min. kcal/h 19.780 19.780 19.780 19.780
min. Wärmeleistung
kW 23 23 23 23
Gas capacity max. 4,51 Nm
3
/h 5,25 Nm
3
/h 3,48 kg/h 3,56 kg/h
Fördermenge Gas
min. 2,35 Nm
3
/h 2,74 Nm
3
/h 1,78 kg/h 1,82 kg/h
Nominal gas pressure
mbar 20 25 37 28/30
Nominaldruck
Max. gas pressure
mbar 25 30 45 35
Maximaldruck
Min. gas pressure
mbar 17 20 25 25
Minimaldruck
Fuel P.C.I.
kcal/Nm
3
8.570 7.370 22.260 29.320
Verbrennungsgas P.C.I.
