Ecoflam MINOR 30.1 - Page 23

pag.23
LB1007 Minor 20.1/30.1
C
TC = TETE COURTE TL = TETE LONGUE
MINOR 20.1 VC MINOR 30.1 VC
N° DESIGNATION code code
1 - POMPE COMPLETE SUNTEC AS 47 K P122 P122
SUNTEC D 57 A - P111/1
2 - BOBINE ELECTROVANNE SUNTEC V504 V504
BRAHMA E 7/L - V501
3 - VANNE SUNTEC V410 V410
BRAHMA E 7/L - V402
4 - JOINT D'ACCOUPLEMENT MP504 MP504
5 - MAMELONS BFR01103/001 BFR01103/001
6 - FLEXIBLES TN 6x700 3/8 G/BIS S906 S906
7 - FILTRE art.70451-006PG S105 S105
8 - MOTEUR 200 W M181/5 -
250 W - M181/6
9 - SUPPORT BFC01102/001
10 - CONDENSATEUR 6,3 µF x 200 W C107/3 -
8 µF x 250 W - C107/4
11 - TURBINE 180 x 40 BFV10102/101 -
180 x 50 - BFV10102/201
12 - TRANSFORMATEUR COFI 1020 T105/1 T105/1
13 - COUVERCLE BFC09101/011 BFC09101/011
14 - HUBLOT BFC02003 BFC02003
15 - VOLUTE BFF06106/011 BFF06106/011
16 - REGLAGE D'AIR SORTIE - -
17 - CONVOYEUR D'AIR BFC08153/001 BFC08151/001
18 - VIS DE REGLAGE D'AIR SORTIE - -
19 - REGLAGE D'AIR ASPIRATION BFC04102/017 BFC04108/003
20 - SOCLE DE COFFRET LANDIS A402 A402
21 - COFFRET DE SECURITE LANDIS LOA 24 A117/1 A117/1
22 - CELLULE LANDIS A207/1 A207/1
23 - BORNES E220
24 - COUVERCLE DE BORNES BFC01101
25 - JOINT DE BRULEUR BFG03053 BFG03053
26 - FILTRE ANTIPARASITES S132/4 S132/4
27 - REGLAGE DE TETE TC - BFA07102/201
TL - BFA07102/101
28 - CABLE HT TC BFE01302/2 GRCAVO/12
TL BFE01302/3 BFE01401/5
29 - GUEULARD TC BFB03002/003 BFB03005/103
TL BFB03001/003 BFB03005/203
30 - ELECTRODE BFE01107 BFE01107
31 - TETE DE COMBUSTION TC GRTT0100/0420 GRTT0100/0531
TL GRTT0100/0421 GRTT0100/0532
32 - PORTE GICLEUR TC GRCR011/1 GRCR011/3
TL GRCR011/2 GRCR011/4
33 - DEFLECTEUR BFD04016 BFD04020
34 - GICLEUR U1350/60S U1500/60S
35 - SUPPORT TC BFA07006/101 BFA07006/101
TL BFA07006/201 BFA07006/201
36 - INDEX - BFT01006/001
37 - VIS DE REGLAGE DE TETE - BFT01005/101
38 - CABLE SUNTEC E1102/1 E1102/1
39 - BOBINE ELECTROVANNE Parker SCEM VE131IND V516 V516
BRAHMA E 7/L V501 V501
40 - VANNE Parker SCEM VE131IND V175/2 V175/2
BRAHMA E 7/L V402 V402
41 - SOCLE RELAIS Finder 5532 R905 R905
42 - RELAIS Finder 5532 R711 R711
