INSTALLATION AND OPERATION GUIDELINES FOR REVERSE OSMOSIS SYSTEMS
ECOSOFT ROBUST 1000, ROBUST 1500, ROBUST PRO, ROBUST 3000
Water
inlet
3/8''
Carbon
lter
Inlet solenoid
valve
Afterlter
pressure
gauge
Low pressure
switch
Booster
pump RO element
Operating
pressure
gauge
Flow
restrictors
Drain
outlet
1/4''
High
pressure
switch
Carbon
lter
Tank
connection
3/8''
Permeate
outlet
3/8''
Flush
valve
Figure 5. RObust 3000
Water Inlet
inlet
3/8''
Sediment
lter
Carbon
lter
Afterlter
pressure
gauge
Low pressure
switch
solenoid
valve
Check
valve
Operating
pressure
gauge
Flow
restrictor
Drain
outlet
1/4''
Tank
connection
3/8''
Permeate
outlet
3/8''
High pressure
switch
Carbon lter
RObustPro lter
Check
valve
RO element
Flow
restrictor
Booster
pump
Flush
valve
Figure 4. RObust PRO
