ES300 Installation & Owner’s Manual
3
ECOSPRING ES300+ PARTS NAMES
NOTE
purchased (depanding on model). Please refer to the real product instead of the picture of this manual.
Water-proof Shield to be purchased by the client, not along with the product accessories.
When ordering repair parts please always give the following information:
1) Model, serial and product number.
2) Parts name.
Front Cover
Electronic Control Box
Compressor
Display
Cover
Front Decorative Board
Cover
(Electric
Heater)
T CO
Electric Heater
ATCO
PTR valve
W ater Outlet
revoC raeR
Junction Box
Junction
Box Cover
Top Cover
Fan Assy
Evaporator
Filter
Water Inlet
Anode
Drain Pipe
Anode
Anode
Air Inlet
Air Outlet
To Next Page
