EC9830 CO ANALYZER OPERATION MANUAL
2-34 98307600 Rev. C-1
INST. DATA
The INST. DATA option allows you to select either off (where no data is
recorded) or record instantaneous data with the following intervals: 1 HOUR, 30
MINUTES, 10 MINUTES, 5 MINUTES, 3 MINUTES OR 1 MINUTE.
TOTAL CAPACITY
When either of the above is set to on, the amount of free memory available for
data logging will be displayed in days. This indicates how much data can be
stored, before the earliest data will start to be overwritten.
Inst. Data
(min)
Total Capacity
(days)
3 106
5 176
10 353
30 1061
60 2123
ERASE LOGGED DATA
When yes is selected and enter is pressed, all the logged data will be erased.
2.5.16 Network Adaptor Menu.
The Network Adaptor Menu allows the user to enter or change the I.P. address,
Netmask and Gateway.
NETWORK ADAPTER MENU
I.P. ADDRESS 0. 0. 0. 0.
NETMASK 0. 0. 0. 0.
GATEWAY 0. 0. 0. 0.
2.5.17 Trend Select Menu
TREND SELECT MENU is the graphic display of the parameters listed.
TREND SELECT MENU
CONCENTRATION
AVG CONCENTRATION
REFERENCE
ZERO OFFSET
SPAN COMPENSATION
SAMPLE FLOW
SAMPLE PRESSURE
Figure 2-24 Trend Select Menu
