ECOVACS DEEBOT R98 - Control Panel & Charging Dock

6
7
EN
EN
2. Package Contents and Technical Specifications
1
5
6
7
2
3
4
Charging Dock
1. Infrared Signal Generators
2. Charging Dock Pins for Robot
3. Automatic Emptying Dust Intake
4. Anti-Slip Strips
5. Charging Dock Pins for
Handheld Vacuum Cleaner
6. Automatic Emptying
Dust Transfer Channel
7. Power Adapter
Dust Bin
1. Dust Bin Handle
2. Filter Net
3. High Efciency Filter
4. Dust Bin Cover
5. Dust Bin Lock
1
2
3
4
5
1
2 3 4 5
Control Panel
1. AUTO Mode Button
2. Wi-Fi Indicator
3. Scheduled Cleaning Indicator
4. Spot Mode Indicator
5. Return to Charger Mode Indicator
