5
Introducing the Motherboard
Table of Motherboard Components
LABEL COMPONENTS
1. SYS_FAN
System cooling fan connector
2. DDR2_1~2
240-pin DDR2 SDRAM slots
3. ATX1
Standard 24-pin ATX power connector
4. CLR_CMOS
Clear CMOS jumper
5. SPK
Internal speaker header
6. PWR_FAN
Power cooling fan connector
7. F_PANEL
Front panel switch/LED header
8. SATA1~2
Serial ATA connectors
9. IDE
Primary IDE connector
10. F_USB1~2
Front Panel USB headers
11. USBPWR_F
Front Panel USB Power Select jumper
12. SPDIFO
SPDIF out header
13. CD_IN
Analog audio input connector
14. F_AUDIO Front panel audio header
15. PCIE
PCI Express x1 slot
16. PCI 32-bit add-on card slot
17. USBPWR_R Rear USB/PS2 Power Select jumper
This concludes Chapter 1. The next chapter explains how to install the motherboard.
