Motherboard User’s Guide
You can use cursor arrow keys to highlight anyone of options on the main menu
page. Press Enter to select the highlighted option. Press the Escape key to leave
the setup utility. Press +/-/ to modify the selected field’s values.
Some options on the main menu page lead to tables of items with installed values
that you can use cursor arrow keys to highlight one item, and press PgUp and
PgDn keys to cycle through alternative values of that item. The other options on
the main menu page lead to dialog boxes requiring your answer OK or Cancel by
selecting the [OK] or [Cancel] key.
If you have already changed the setup utility, press F10 to save those changes
and exit the utility. Press F1 to display a screen describing all key functions.
Press F9 to install the setup utility with a set of default values.
Standard CMOS Setup Page
This page displays a table of items defining basic information about your
system.
Date & Time
These items set up system date and time.
Primary IDE Master/Primary IDE Slave/Secondary IDE Master/Secondary
IDE Slave/SATA1/2
Use these items to configure devices connected to the Primary/Secondary IDE
channels. To configure an IDE hard disk drive, choose Auto. If the Auto setting
fails to find a hard disk drive, set it to User, and then fill in the hard disk
characteristics (Size, Cyls, etc.) manually. If you have a CD-ROM drive, select
the setting CDROM. If you have an ATAPI device with removable media (e.g. a
ZIP drive or an LS-120), select Floptical. In addition, this motherboard supports
two SATA channels and each channel allows one SATA device to be installed.
Use these items to configure each device on the IDE channel.
CMOS SETUP UTILITY – Copyright (C) 1985-2003, American Megatrends, Inc.
Standard CMOS Setup
System Time 00:01:18
System Date Mon 10/03/2005
Primary IDE Master Hard Disk
Primary IDE Slave Not Detected
Secondary IDE Master CD/DVD ROM
Secondary IDE Slave Not Detected
S-ATA1 Not Decteted
S-ATA2 Not Detected
Floppy A 1.44 MB 3 1/2”
Floppy B Disabled
Help Item
User [Enter], [TAB] or [SHIFT-TAB] to
select a field.
Use [+] or [-] to configure system
time.
: Move Enter: Select +/-/: Value F10: Save Esc: Exit
F1: General Help F9: Optimized Defaults
