Chapter 3: BIOS Setup Utility
DRAM Frequency
This item shows the frequency of the DRAM in your system.
Memory Voltage
This item determines the DDR voltage adjustment.
CPU Vcore Voltage
This item enables users to adjust the CPU voltage.
H/W Thermal Protect Shutdown
This item provides the function of CPU temperature pro
Hardware Monitor Page
This page sets up some parameters for the hardware monitoring function of this
motherboard.
CPU/System Temperature
These items display CPU and system temperature measurement.
FANs & Voltage Measurements
These items indicate cooling fan speeds in RPM and the various system voltage
measurements.
Shutdown For Power Thermal
When the CPU temperature exceeds your setup range, the system will be
automatically shutdown.
CMOS SETUP UTILITY – Copyright (C) 1985-2004, American Megatrends, Inc.
Hardware Monitor Setup
*** System Hardware Monitor***
Vcore :1.488V
Vdimm :2.592V
Vcc5V :5.187V
5VSB :4.972V
CPU FAN Speed :2860 RPM
SYSTEM FAN Speed :0 RPM
CPU Temperature :38°C/100°F
SYSTEM Temperature :28°C/82°F
POWER Temperature :35°C/95°F
Shutdown For Power Thermal Disabled
Help Item
: Move Enter: Select +/-/: Value F10: Save Esc: Exit
F1: General Help F9: Optimized Defaults
Option
Disabled
40°C/104°F
50°C/122°F
60°C/140°F
70°C/158°F
80°C/176°F
