3
Chapter 1: Introduction
• One serial port
• One parallel port
• One VGA port
• Four back-panel USB2.0 ports
• One LAN port (optional)
• Audio jacks for microphone, line-in and line-out
Fast Ethernet LAN (optional)
• Supports 10/100Mbps operation and half/full duplex operation
• IEEE 802.3/802.3u compliant
• Supports IEEE 802.3u clause 28 auto negotiation
• Supports operation under Link Down Power Saving mode
• Supports Base Line Winder (BLW) compensation
• Adaptive Equalization
USB 2.0
• Compliant with Universal Serial Bus Specification Revision 2.0
• Compliant with Intel’s Enhanced Host Controller Interface Specification
Revision 1.0
• Compliant with Universal Host Controller Interface Specification
Revision 1.1
• PCI multi-function device consists of two UHCI Host Controller cores
for full-/low-speed signaling and one EHCI Host Controller core for
high-speed signaling
• Root hub consists 4 downstream facing ports with integrated physical
layer transceivers shared by UHCI and EHCI Host Controller, up to
eight functional ports
• Support PCI-Bus Power Management Interface Specification release 1.1
• Legacy support for all downstream facing ports
BIOS Firmware
This motherboard uses AMI BIOS that enables users to configure many system
features including the following:
• Power management
• Wake-up alarms
• CPU parameters and memory timing
• CPU and memory timing
The firmware can also be used to set parameters for different processor clock
speeds.
Dimensions
• Micro ATX form factor of 244 x 200 mm
Note: Hardware specifications and software items are subject to change
without notification.
