A68M-C4DL USER MANUAL
Chapter 1
Table of Motherboard Components
LABEL COMPONENTS
1. CPU Socket AMD A series APU in the FM2/FM2+ package
2. CPU_FAN CPU cooling fan connector
3. SPK Speaker header
4. DDR3_1~2 240-pin DDR3 SDRAM slots
5. ATX_POWER Standard 24-pin ATX power connector
6. USB3F Front panel USB 3.0 header
7. SATA1~4 Serial ATA 6Gb/s connectors
8. F_PANEL Front panel switch/LED header
9. F_USB1~2 Front panel USB 2.0 headers
10. USBPWR_F Front panel USB power select jumper
11. COM Onboard serial port header
12. LPT Printer header
13. CASE Case open header
14. F_AUDIO Front panel audio header
15. PCI 32-bit add-on card slot
16. CLR_CMOS Clear CMOS jumper
17. PCIEX1 PCI Express x1 slot
18. PCIEX16 PCI Express slot for graphics interface
19. SYS_FAN System cooling fan connector
20. USBPWR_R Rear USB 2.0/PS2 power select jumper
21. USB3PWR_R Rear USB 3.0/PS2 power select jumper
22. ATX12V 4-pin +12V power connector
