Chapter 3
A75F2-M2 USER
MANUAL
29
The Advanced menu items allow you to change the settings for the CPU and other
system.
Advanced Menu
LAN Configuration Param-
eters
Main
Advanced
Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous V
alues
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
LAN Configuration
PC Health Status
Power Management Setup
ACPI Settings
CPU Configuration
SA
T
A
Configuration
USB Configuration
Super IO Configuration
Trusted Computing
32
34
Table of Contents
Default Chapter
2
About the Manual
2
Canadian Department of Communications
2
Declaration of Conformity
2
Table of Contents
3
Chapter 1 Introducing the Motherboard
5
Introduction
5
Pakage Contents
5
Specifications
6
Motherboard Components
8
I/O Ports
10
Chapter 2 Installing the Motherboard
11
Safety Precautions
11
Installing the Motherboard in a Chassis
11
Checking Jumper Settings
12
Installing Hardware
13
Installing the Processor
13
Installing the CPU Cooler
14
Installing Memory Modules
15
Installing Add-On Cards
16
Connecting Optional Devices
18
Installing a SATA Hard Drive
24
Connecting Case Components
25
Front Panel Header
27
Chapter 3 Using BIOS
29
About the Setup Utility
29
The Standard Configuration
29
Entering the Setup Utility
29
Resetting the Default CMOS Values
30
Using BIOS
30
BIOS Navigation Keys
31
Main Menu
32
Advanced Menu
33
Lan Configuration
34
Pc Health Status
35
Power Management Setup
37
Acpi Configuration
38
Cpu Configuration
39
Sata Configuration
40
Usb Configuration
41
Super Io Configuration
42
Trusted Computing
44
Chipset Menu
45
South Bridge
46
MB Intelligent BIOS III) Menu
47
Boot Menu
49
Security Menu
51
Exit Menu
54
Updating the BIOS
55
Chapter 4 Using the Motherboard Software
57
Auto-Installing under Windows XP/7/8
57
Running Setup
57
Manual Installation
59
ECS Utility Software (Intelligent EZ Utility)
59
Chapter 5 Setting up AMD A75 RAID Configuration
61
Setting up a Bootable RAID Array
61
Assigning the Disks
64
Installing the Raid Drivers
66
Chapter 6 Trouble Shooting
69
Start up Problems During Assembly
69
Start up Problems after Prolong Use
70
Maintenance and Care Tips
70
Basic Troubleshooting Flowchart
71
