Core Clock Multiplier (Auto)
Use this item to set the core clock multiplier.
Memory Clock (Auto)
This item is used to set the memory clock.
Memory Timing Configuration (Auto)
This item shows the information of Memory Timing Configuration.
Memory Clock DCT0/1 is (None/DDR-1333/667 Mhz)
These items show current memory clock of DCT0/1.
Command Rate (N/A/1 T)
This item is used to set command rate.
CAS# Latency (tCL) (N/A/9 CLK)
This item determines the operation of DDR SDRAM memory CAS (column address
strobe). It is recommended that you leave this item at the default value. The 2T
setting requires faster memory that specifically supports this mode.
RAS# to CAS# Delay (tRCD) (N/A/9 CLK)
This item specifies RAS# to CAS# delay to Rd/Wr command to the same bank.
Row Precharge Time (tRP) (N/A/10 CLK)
This item specifies Row precharge to Active or Auto-Refresh of the same bank.
RAS# Active Time (tRAS) (N/A/24 CLK)
This item specifies the RAS# active time.
SB Spread Spectrum (Enabled)
This item enables or disables the SB Clock Spread Spectrum.
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have
installed in your system.
M.I.B III (MB Intelligent BIOS III) Menu
Main Advanced Chipset M.I.B III Boot Security Exit
Core Clock multiplier
Core Clock multiplier Auto
Memory Clock Auto
Memory Timing Configuration Auto
Memory Clock DCT0 is: None
Command Rate N/A
CAS# Latency(tCL) N/A
RAS# to CAS# Delay (tRCD) N/A
Row Precharge Time (tRP) N/A
RAS# Active Time (tRAS) N/A
Memory Clock DCT1 is: (DDR-1333/667Mhz)
Command Rate 1 T
CAS# Latency(tCL) 9 CLK
RAS# to CAS# Delay (tRCD) 9 CLK
Row Precharge Time (tRP) 10 CLK
RAS# Active Time (tRAS) 24 CLK
SB Spread Spectrum Enabled
CPU Over-clocking Func. Disabled
IGD Over-clocking Func. Disabled
+/- : Change Opt.
Enter/Dbl Click : Select

: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
ESC/Right Click: Exit

F4: Save & Exit
