Chapter 3
A75F2-M2 USER MANUAL
33
Power Management Setup
This page sets up some parameters for system power management operation.
Resume By PME (Disabled)
This item specify whether the system will be awakened from power saving modes
when activity or input signal of the specified hardware peripheral or components is
detected.
Resume By USB 1.x/2.0 (S3) (Disabled)
This item allows you to enable/disable the USB device wakeup function from S3
mode.
EUP Function (Enabled)
This item allows user to enable or disable EUP support.
Press <Esc> to return to the Advanced Menu page.
Resume By RING (Disabled)
An input signal on the serial Ring Indicator (RI) line (in other words, an incoming call
on the modem) awakens the system from a soft off state.
Power LED Type (Dual Color LED)
This item shows the type of the Power LED.
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
About Resume by RING
Power Management Setup
Resume By RING Disabled
Resume By PME Disabled
Resume By USB 1.x/2.0 (S3) Disabled
Resume By PS2 KB (S3) Disabled
Resume By PS2 MS (S3) Disabled
EUP Function Enabled
Power LED Type Dual Color LED
Resume By PS2 KB (S3) (Disabled)
This item allows you to enable or disable keyboard activity to awaken the sytem
from power saving mode.
Resume By PS2 MS (S3) (Disabled)
This item allows you to enable or disable mouse activity to awaken the sytem from
power saving mode.
