PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Scroll to this item and press <Enter> to view the following screen:
Smart Fan Function
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select

: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
CPU Tct1 : +63
CPU Fan Speed : 3134 RPM
CPU Voltage : +1.464 V
DIMM Voltage : +1.592 V
PCH Voltage : +1.243 V
Smart Fan Function
PC Health Status
CPU Smart Fan Control (Enabled)
This item enables you to define the CPU by smartly adjusting the CPU Fan. When it
is set at certain temperature, the CPU Fan PWM value will change accordingly.

Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
CPU Smart Fan Control Enabled
Smart Fan Mode Normal
High Limit Temperature 60
Low Limit Temperature 30
High Limit PWM 255
Low Limit PWM 110
