34
Using BIOS
HDMI Audio (Enabled)
This item is used to enable or disable the onboard audio chip.
DCT Unganged Mode (Always)
This item is used to select the DCT mode (DRAM Controller mode).
Init Display First (PCI)
Use this item to select which graphics controller to use as the primary boot devices.
Press <Esc> to return to the main menu setting page.
Integrated Peripherals
This page sets up some parameters for peripheral devices connected to the system.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Integrated Peripherals
OnBoard IDE Controller Enabled
OnBoard SATA Mode Enabled
SATA Configuration IDE
OnBoard AUDIO Function Enabled
OnBoard LAN Function Enabled
OnBoard LAN Boot ROM Disabled
Serial Port1 Address Disabled
USB Functions Enabled
Legacy USB Support Enabled
Help Item
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Default settings
F1:General Help
: Move
mnlk
Options
DISABLED: disables the
integrated IDE
Controller.
Enabled : ensables both
Controller.
OnBoard IDE Controller (Enabled)
SATA Configuration (IDE)
Use this item to show the Serial ATA Configuration options: Disabled, Compatible,
Enhanced.
OnBoard AUDIO Function (Enabled)
Use this item to enable or disable the onboard Audio function.
OnBoard LAN Function (Enabled)
Use this item to enable or disable the onboard LAN function.
OnBoard LAN Boot ROM (Disabled)
Use this item to enable or disable the booting from the onboard LAN or a network
add-in card with a remote boot ROM installed.
Use this item to enable or disable the onboard IDE interface.
OnBoard SATA Mode (Enabled)
Use this item to enable or disable the onboard SATA mode.
Memory Hole Remapping (Enabled)
This item allows users to enable or disable memroy hole remapping.
To Next Page
