Using BIOS
M.I.B. II (MB Intelligent BIOS II)
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have installed
in your system.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
M.I.B. II (MB Intelligent BIOS II)
Help Item
AMD Athlon (tm) II X4 820 Processor
Speed : 2800MHz, NB CLK: 2000MHz
Physical Count : 1
Logical Count : 4
Current CPU Frequency 2800MHz
Current CPU Voltage 1.2750v
Current NB Frequency 2000MHz
DIMM Voltage Default 1.60v
NB Voltage Default 1.15v
SB Voltage Default 1.20v
Memory Configuration Press Enter
Advanced Clock Calibration Disabled
CoreX Control Disabled
HT Frequency Auto
CPU/HT Reference Clock (MHz) 200
Auto Detect DIMM/PCI Clk Enabled
Spread Spectrum Enabled
CPU Voltage Disabled
DIMM Voltage Disabled
NB Voltage +30mV
SB Voltage 1.25 v
: Move F10: Save ESC: Exit
+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
mnlk
f
Memory Configuration
f
Scroll to this item and press <Enter> to view the following screen:
Help Item
Memory CLK : N/A,667MHz
CAS Latency (Tcl) : N/A,9CLK
RAS/CAS Delay (Trcd) : N/A,9CLK
Row Precharge Time (Trp) : N/A,9CLK
Min Active RAS (Tras) : N/A,24CLK
RAS/RAS Delay (Trrd) : N/A,4CLK
Row Cycle (Trc) : N/A,33CLK
Memory Configuration
DRAM Frequency Auto
DRAM Timing Mode Auto
Bank Interleaving Auto
Channel Interleaving XOR of Address bits
: Move F10: Save ESC: Exit
+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
mnlk
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Memory Configuration
Auto
Limit
Manual
Options
Adjust SB Voltage
1.35v
1.3v
1.25v
1.2v
WARNING:
Doing overvoltage
may result in damage
in System
To Next Page
