5. Use the arrow keys to select “Select Physical Disks” and press <Enter> ,
then set the “Physical Disk 0:1:0, SATA, 500.0 GB, Ready” and “Physical
Disk 0:1:1, SATA, 1.0 TB, Ready” to “Enabled” as below.
Figure 1.7 Select RAID Level Screen
Main Advanced Chipset M.I.B. X Security Boot Exit
Select Media Type: BOTH
Select Interface Type: SATA
Minimum required number of disks: 1
Maximum allowed number of disks: 8
Physical Disk 0:1:0, SATA, 500.0 GB, Ready Enabled
Physical Disk 0:1:1, SATA, 1.0 TB, Ready Enabled
Apply Changes
6. Press <ESC> to return to the “RAIDXpert2 Configuration Utility” as below
and use the arrow keys to select “Manage Array Properties” and press
<Enter>.
Figure 1.8 Array Management Screen
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Main Advanced Chipset M.I.B. X Security Boot Exit
Create Array
Manage Arrary Properties
Delete Array
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Displays and manages Array
properties.
