B85H3-M9 USER MANUAL
CASE
CLR_CMOS Jumper
ME_UNLOCK
UNLOCK
1-2: NORMAL
Before clearing the CMOS, make sure to turn off the system.
CLR_CMOS
312
CPU_FAN
LOCK
2-3: CLEAR CMOS
SYS_FAN
Sensor
PWM
System Ground
Power +12V
1
Sensor
PWM
System Ground
Power +12V
1
SPK
1
VCC Signal
Key
GND
1
IntruderGND
USB3F
1
SSTX1-
USB POWER
SSRX1-
SSRX1+
GND
SSTX1+
GND
D1-
D1+
USB POWER
SSRX0+
SSRX0-
GND
SSTX0+
GND
D0-
D0+
NC
SSTX0-
