B85H3-M9 USER MANUAL
1
Brief Introduction
CPU
Specifications
•Intel
®
B85 Chipset
Chipset
• Dual-channel DDR3 memory architecture
• 2 x 240-pin DDR3 DIMM sockets support up to 16 GB
• Supports DDR3 1600/1333 MHz DDR3 SDRAM
Memory
• 1 x PCI Express x16 Gen3 slot
• 1 x PCI Express x1 slot
• Supported by Intel
®
B85 Express Chipset
- 4 x Serial ATA 6Gb/s devices
Expansion
Slots
Storage
• 1 x PS/2 keyboard and PS/2 mouse connectors
• 1 x HDMI port or DVI port*
• 1 x VGA port
• 2 x USB 3.0 ports
• 1 x RJ45 LAN connector
• 2 x USB 2.0 ports
• 1 x Audio port (1x Line in, 1x Line out, 1x Mic_in Rear)
Rear Panel I/O
• Realtek RTL8111G Giga LAN (Colay 10/100)
- 10/100/1000 Fast Ethernet Controller
- Wake-on-LAN and remote wake-up support
• LGA1150 socket for Intel
®
Haswell Processor
• Supports TDP up to 65W
Note: Please go to ECS website for the latest CPU support list.
• 1 x 24-pin ATX_Power Supply connector
• 1 x 4-pin ATX12V Power connector
• 1 x 4-pin CPU_FAN connector
• 1 x 4-pin SYS_FAN connector
• 2 x USB 2.0 headers support additional four USB 2.0 ports
• 1 x USB 3.0 header supports additional two USB 2.0 ports
• 4 x Serial SATA 6Gb/s connectors
• 1 x COM header
• 1 x Case open header
• 1 x LDC header
• 1 x Front Panel audio header
• 1 x Front Panel switch/LED header
• 1 x Speaker header
• 1 x ME_UNLOCK header
• 1 x CLR_CMOS jumper
Internal I/O
Connectors &
Headers
• VIA VT1705
- 6 Channel High Definiton Audio Codec
- Compliant with HD audio specification
Audio
LAN
Note: *Please take the actual motherboard as standard.
