Introducing the Motherboard

Table of Motherboard Components

LABEL COMPONENTS

LGA775 socket for Intel

Yorkfield/Wolfdale/Core

™

Quad

(

Q6600/Q6700 G0

)

/Pentium

Dual-Core/

Celeron

4xx Series

rocessors

2. CPU_FAN CPU cooling fan connector

3. DDR2_1~2 240-pin DDR2 SDRAM slots

4. ATX_POWER Standard 24-pin ATX power connector

5. SATA1~4 Serial ATA connectors

6. F_USB1~2 Front Panel USB headers

7. SPK Speaker header

8. USBPWR_F Front Panel USB Power Select Jumper

9. F_PANEL Front panel switch/LED header

10. CLR_CMOS Clear CMOS jumper

11. IDE Primary IDE channel

12. FDD Floppy disk drive connector

13. CD_IN Analog audio input connector

14. F_AUDIO Front panel audio header

15. SPDIFO SPDIF out header

16. PCI1~2 32-bit add-on card slots

17. PCIE PCI Express x1 slot

18. PCIEX16 PCI Express x16 graphics card slot

19. USBPWR_R Rear Panel USB PS/2 Power Select Jumper

20. SYS_FAN System cooling fan connector

21. ATX12V 4-pin +12V power connector

22. LPT Onboard parallel port header

1. CPU Socket

This concludes Chapter 1. The next chapter explains how to install the motherboard.

Other manuals for ECS G31T-M7

Questions and Answers:

Need help?

Do you have a question about the ECS G31T-M7 and is the answer not in the manual?

General

Number of memory slots	2
Maximum internal memory	4 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
Compatible processor series	Intel Core 2 Duo, Intel Core 2 Quad
S/PDIF out connector	Yes
Number of COM connectors	1
Number of SATA connectors	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Audio chip	VIA VT1708B
Power source type	ATX
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
BIOS type	AMI
BIOS memory size	32 Mbit
