32
Using BIOS
Advanced Chipset Setup
This page sets up more advanced information about your system. Handle this page with
caution. Any changes can affect the operation of your computer.
Configure DRAM Timing by SPD (Enabled)
When this item is set to enable, the DDR timing is configured using SPD. SPD (Serial
Presence Detect) is located on the memory modules, BIOS reads information coded in SPD
during system boot up.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Advanced Chipset Setup
DRAM Frequency Auto
Configure DRAM Timing by SPD Enabled
Share Memory Size Enabled, 8MB
DVMT Mode Select DVMT Mode
Help Item
Options
Auto
667 MHz
800 MHz
DVMT/FIXED Memory 256MB
DRAM Frequency (Auto)
This item enables users to adjust the DRAM frequency. The default setting is auto and we
recommend users leave the setting unchanged. Modify it at will may cause the system to be
unstable.
DVMT Mode Select (DVMT Mode)
This item allows you to select the DVMT operating mode.
DVMT/FIXED Memory (256MB)
When set to Fixed Mode, the graphics driver will reserve a fixed portion of the system
memory as graphics memory, according to system and graphics requirements.
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move
mnlk
Share Memory Size (Enabled, 8MB)
This item lets you allocate a portion of the main memory for the onboard
VGA display application.
Press <Esc> to return to the main menu setting page.
Memory Remap Feature Enabled
Memory Remap Feature (Enabled)
This item allows you to remap the overlapped PCI memory above the total physical
memory if you have a 64 bit OS and 4 GB of RAM.
To Next Page
