31
Using BIOS
Primary IDE Master/Slave; SATA1~4
f
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Primary IDE Master
Help Item
Select the type
of device connected
to the system.
Your computer has one IDE channel and each channel can be installed with one or two
devices (Master and Slave). In addition, this motherboard supports four SATA chan-
nels and each channel allows one SATA device to be installed. Use these items to
configure each device on the SATA channel.
Primary IDE Master
Device
Vendor
LBA Mode
PIO Mode
Async DMA
Ultra DMA
Type Auto
PIO Mode Auto
DMA Mode Auto
: ATAPI CDROM
: DVD-ROM DDU1632
: Supported
: 4
: MultiWord DMA-2
: Ultra DMA-2
mnlk
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Load Default Settings
F1: General Help
Press <Esc> to return to the Standard CMOS Setup page.
Type (Auto)
Use this item to configure the type of the IDE device that you specify. If the feature
is enabled, it will enhance hard disk performance by reading or writing more data
during each transfer.
PIO Mode (Auto)
Use this item to set the PIO mode to enhance hard disk performance by optimizing
the hard disk timing.
DMA Mode (Auto)
DMA capability allows user to improve the transfer-speed and data-integrity for
compatible IDE devices.
IDE BusMaster (Enabled)
This item enables or disables the DMA under DOS mode. We recommend you to leave
this item at the default value.
Press <Esc> to return to the main menu setting page.
