ECS G41T-M User Manual

40
Using BIOS
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
SMART Fan Function Enabled
Smart Fan Mode Quiet
SMART Fan start PWM value 20
CPU DeltaT1 +3
SMART Fan start TEMP. (°C) 68
SMART Fan Slope PWM value 14 PWM value/°C
CPU FAN Full Limit Temp 75°C
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Load Default Settings
F1:General Help
: Move
mnlk
Options
Normal: auto adjusts
depending on the CPU
temperature.
Quiet: auto minimizes
fan speed for quiet en-
vironment operation.
Silent: auto restricts fan
speed to make system
more quietly.
Manual: the fan adjust
depending on user’s
parameter.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
SMART Fan Function Enabled
Smart Fan Mode Silent
SMART Fan start PWM value 5
CPU DeltaT1 +3
SMART Fan start TEMP. (°C) 70
SMART Fan Slope PWM value 12 PWM value/°C
CPU FAN Full Limit Temp 80°C
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Load Default Settings
F1:General Help
: Move
mnlk
Options
Normal: auto adjusts
depending on the CPU
temperature.
Quiet: auto minimizes
fan speed for quiet en-
vironment operation.
Silent: auto restricts fan
speed to make system
more quietly.
Manual: the fan adjust
depending on user’s
parameter.

ECS G41T-M Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
S/PDIF out connector	Yes
Number of SATA connectors	4
Number of Parallel ATA connectors	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Audio chip	VIA VT1708B
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Graphics card	GMA X4500
Networking features	Fast Ethernet
ACPI version	1.0
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	204 mm
Width	244 mm
