Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
1. CPU Socket
LGA775 socket for Core
TM
2
uad
Core
TM
2 Duo
Pentium
®
Dual Core
Celeron
®
Dual Core
Celeron
®
400 series processors
2. CPU_FAN CPU cooling fan connector
3. DDR3_1~2 240-pin DDR3 SDRAM slots
4. ATX_POWER Standard 24-pin ATX power connector
5. IDE Primary IDE channel
6. SPK Speaker header
7. CLR_CMOS Clear CMOS jumper
8. USBPWR_F Front panel USB power select jumper
9. SATA1~2 Serial ATA connectors
10. F_USB1~2 Front panel USB headers
11. F_PANEL Front panel switch/LED header
12. COM Onboard serial port header
13. SPDIFO SPDIF out header
14. LPT Onboard parallel port header
15. F_AUDIO Front panel audio header
16. PCI1~2 32-bit add-on card slots
17. PCIE PCI Express x 1 slot
18. CASE Chassis detect header
19. PCIEX16 PCI Express x16 graphics card slot
20. USBPWR_R Rear panel USB/PS2 power select jumper
21. ATX12V 4-pin +12V power connector
