3
Introducing the Motherboard
Onboard LAN (optional)
The motherboard comes with the following expansion options:
• One PCI Express x16 slots for Graphic Interface
• One PCI Express x1 slot
• Two 32-bit PCI v2.3 compliant slots
• One IDE connector that supports two IDE devices
• Two 7-pin SATA connectors
Expansion Options
• Two PS/2 ports for mouse and keyboard
• One VGA port
• Four USB ports
• One LAN port
• Audio jacks for microphone, line-in and line-out
The motherboard has a full set of I/O ports and connectors:
Integrated I/O
• Compliants with PCI Express. 1.1
• Integrated 10/100 transceiver
• Supports Wake-on-LAN and remote wakeup
• Fully compliant with IEEE 802.3, IEEE802.3u
Audio
This motherboard may support either of the following Audio chipsets:
• 5.1 Channel High Definition Audio Codec
• Exceeds Microsoft Windows Logo Program (WLP) Requirements
• ADCs support 44.1K/48K/88.2K/96K/192KHz sample rate
• Power Support: Digital: 3.3V; Analog: 5.0V
1.Some hardware specifications and software items are subject to change
without prior notice.
2.Due to chipset limitation, we recommend that motherboard be oper-
ated in the ambiance between 0 and 50°C.
The firmware can also be used to set parameters for dif
ferent processor clock
speeds.
• Power management
• Wake-up alarms
• CPU parameters
• CPU and memory timing
BIOS Firmware
This motherboard uses AMI BIOS that enables users to configure many system
features including the following:
• Compliants with PCI Express. 1.1
• Integrated 10/100/1000 transceiver
• Supports Wake-on-LAN and remote wakeup
• Fully compliant with IEEE 802.3, IEEE802.3u, IEEE802.3ab
