Using BIOS
Press <Esc> to return to the PC Health Status page.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Load Default Settings
F1:General Help
: Move
mnlk
Options
Press <Esc> to return to the Smart Fan Mode page.
ECS supports the latest PECI host technology. While using Core
TM
2 Quad or
Core
TM
2 Duo CPU which supports PECI, the original images of the BIOS
item “PC Health Status” and “Smart FAN Function” will be replaced by
PECI mode and negative number. (The max data from PECI is zero.)
Help Item
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
PC Health Status
f
-=- System Hardware Monitor-=-
Smart Fan Function Press Enter
Shutdown Temperature Disabled
CPU Temperture : 40°C/104°F
CPU Fan Speed : 963 RPM
CPU Vcore : 1.280 V
VDIMM : 1.496 V
Case Open Warning Disabled
Chassis Opened No
mnlk
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Load Default Settings
F1: General Help
Smart Fan Function Enabled
SMART Fan Mode Manual
SMART Fan start PWM value 5
CPU DeltaT +3
SMART Fan start Offset (-) 26
Fan1 Slope PWM value/1 Unite 6
Fan1 Full Speed Offset (-) 6
Normal: auto adjusts
depending on the CPU
temperature.
Quiet: auto minimizes
fan speed for quiet
environment operation.
Silent: auto restricts
fan speed to make
system more quietly.
Manual: the fan adjust
depending on user’s
parameter.
