4
Introducing the Motherboard
• Intel G41 & ICH7 Express Chipset
North Bridge: Intel G41 South Bridge: ICH7
• LGA775 socket for Core
TM
2 Extreme/Core
TM
2 Quad/Core
TM
2 Duo/Pentium
®
Dual Core/Celeron
®
Dual Core/Celeron
®
400/
Pentium
®
4/Celeron
®
D series processors
• Dual-channel DDR3 memory architecture
• 2 x 240-pin DDR3 DIMM sockets support up to 8 GB
• Supports DDR3 1333(OC)/1066/800 SDRAM
• 1 x PCI Express x16 slot
• 1 x PCI Express x1 slot
• 2 x PCI slots
• Supported by Intel ICH7 Express Chipset
• 4 x Serial ATA 3.0 Gb/s devices
• 1 x Ultra DMA100/66 port
• VIA VT1705 6-Ch High Definition audio CODEC
• Realtek 8105E 10/100 Lan (Realtek 8111E Giga Lan Op-
tional)
• 1 x PS/2 keyboard & PS/2 mouse connectors
• 1 x VGA port
• 4 x USB 2.0 ports
• 1 x RJ45 LAN connector
• 1 x Audio port (Line in, microphone in, line out)
Chipset
Memory
Expansion
Slots
Storage
Audio
LAN
Rear Panel I/O
Internal I/O
Connectors &
Headers
• AMI BIOS with 8Mb SPI Flash ROM
• Supports Plug and Play, STR(S3)/STD(S4), Hardware moni-
tor, Multi Boot
• Supports ACPI & DMI
• Audio, LAN can be disabled in BIOS
• F11 hot key for boot up devices option
System BIOS
Form Factor
• Micro ATX Size, 244mm x 170mm
CPU
Specifications
• 1 x 24-pin ATX power supply connector
• 1 x 4-pin 12V Power connector
• 1 x 4-pin CPU_FAN connector
• 1 x Speaker header
• 1 x Front panel audio header
• 1 x Front panel switch/LED header
• 1 x SPDIF out header
• 1 x Serial port header (COM)
• 4 x SATA 3Gb/s connectors
• 2 x USB 2.0 headers
• 1 x Chassis intrusion header
• 1 x Parallel port header (LPT)
• 1 x CLR_CMOS header
