12
Installing the Motherboard
Installing Memory Modules
This motherboard accommodates two or four (optional) memory modules. It runs at
dual-channel DDR3 1066/800 MHz memory speed. The total memory capacity is 8
GB.
You must install at least one module in any of the two or four slots, total memory
capacity is 8 GB.
DDR3 SDRAM memory module table
DDR3 800 400 MHz
Memory module Memory Bus
DDR3 1066 533 MHz
ff
Channel A: DDR3_1, DDR3_2
Channel B: DDR3_3, DDR3_4
When there’re four DDR3 memory sockets (DDR3_1, DDR3_2, DDR3_3 and
DDR3_4), they are divided into two channels and each channel has two memory
sockets as following:
DDR3_1 DDR3_2 DDR3_3 DDR3_4
1 DIMM Populated
2 DIMMs Populated Populated
4 DIMMs
Populated
(Single Side)
Populated
(Single Side)
Populated
(Single Side)
Populated
(Single Side)
Mode
Sockets
Recommend memory configuration
ff
Do not remove any memory module from its antistatic packaging until you
are ready to install it on the motherboard. Handle the modules only by
their edges. Do not touch the components or metal parts. Always wear a
grounding strap when you handle the modules.
1. For best performance and compatibility, we recommend that users give
priority to the orange DIMMs (DDR3_1/DDR3_3) when installing DIMMs.
2. We suggest users not mix memory type. It is recommended to use the
same brand and type memory on this motherboard.
3. You may not populate three DIMMs at one time, and if the four DIMMs
are populated at one time, the memory will run at 800MHz.
