4
Introducing the Motherboard
• Intel
®
G41 Northbridge (NB) and Intel
®
ICH7 Southbridge (SB)
chipsets
• LGA775 socket for latest Intel
®
Conroe/Presler/Wolfdale/
Yorkfield processors
• Supports “Hyper-Threading” technology CPU
• Dual-channel DDR3 memory architecture
• 4 x 240-pin DDR3 DIMM sockets support up to 8 GB or 2 x
240-pin DDR3 DIMM sockets support up to 8 GB (optional)
• Supports DDR3 1066/800 DDR3 SDRAM
• 1 x PCI Express Gen2 x16 slot
• 1 x PCI Express x1 slot
• 2 x PCI slots
• Supported by Intel
®
ICH7 Southbridge (SB) chipset
• 4 x Serial ATA 3.0 Gb/s Host Controllers
• Realtek ALC 662VC supports 5 channel HD audio
• RTL8111DL PCIE GigaLAN Controller & RTL8103EL 10/100M
LAN (optional)
• 1 x PS/2 keyboard & PS/2 mouse connector
• 1 x DVI port (optional)
• 1 x VGA port
• 1 x COM port (optional)
• 4 x USB ports
• 1 x RJ45 LAN connector
• 1 x LPT port (optional)
• 1 x Audio port (Line in, microphone in and line out)
• 1 x 24-pin ATX Power Supply connector, 4-pin 12V connec-
tor
• 4 x Serial ATA connectors
• 2 x USB 2.0 headers support additional 4 USB ports
• 1 x Front panel header
• 2 x 1394a headers (optional)
• 1 x COM header (optional)
• 1 x SPI debug header
• 1 x SPDIF out header
• 1 x Front panel audio header
• 1 x SPK header
• 1 x CD_In header
• 1 x Chassis detect header
• 1 x TPM header (optional)
• CPU_FAN/SYS_FAN connectors
Chipset
Memory
Expansion
Slots
Storage
Audio
Giga LAN
Rear Panel I/O
Internal I/O
Connectors &
Headers
• AMI BIOS with 8Mb SPI ROM
• Supports Plug and Play 1.0A, APM 1.2, Multi Boot, DMI
• Supports ACPI revision 1.0 specification
System BIOS
Form Factor
• Micro ATX Size, 244mm x 244mm
CPU
Specifications
