Introducing the Motherboard
•
AMI BIOS with 64Mb SPI Flash ROM
•
Supports Plug and Play
, S1 / STR (S3) / STD (S4) , Hard-
ware monitor
•
Supports
ACPI & DMI
•
Audio, LAN, can be disabled in BIOS
•
Supports Dual Display
•
F7 hot key for boot up devices option
Form Factor
•
Mini ITX Size, 170mm x 170mm
System BIOS
Driver
•
Windows 7 (32bit/ 64bit)
•
Windows 8.1 (32bit/ 64bit)
•
Windows 10
Certification
•
RoHS
•
EMI: FCC, CE
•
WHQL: TBD
4
6
Table of Contents
Chapter 1 Introducing the Motherboard
1
Ethernet LAN
3
Expansion Options
3
BIOS Firmware
3
Specifications
4
Motherboard Components
6
