Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
1. CPU Socket LGA1151 socket for Intel Skylake processors
2. LPT Printer header
3. COM3~6 Onboard serial port headers
4. ATX_12V 4-pin +12V power in connector
5. F_PANEL Front panel switch/LED header
6. CLR_CMOS Clear CMOS button with jumper
7. BT Battery
8. PCIEX16 PCI Express slot for graphics interface
9. F_USB1~2 Front panel USB2.0 header
10. F_AUDIO Front audio header
11. SPKR Speaker
12. CASE CASE open header
13. PCIE PCI Express Gen2 x1 slot
14. SYS_FAN 4-pin System cooling fan connector
15. DIO 4 bit GPIO (GPI*4, GPO*4)
16. SATA1~2 Serial ATA 6.0Gb/s connectors (one supports SATA DOM)
17. SATA_DOM SATA DOM header
18. LCD_PWR LVDS Power select jumper
19. VCON LVDS power & inverter jumper
20. LVDSPW_CON LCD backlight power & Brightness control header
21. LVDS LVDS connector
22. ATX_POWER Standard 24-pin ATX power connector
23. CPU_FAN 4-pin CPU cooling fan connector
24. SO-DIMM1~2 DDR4 2133 SDRAM slot
