6
Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
LGA1155 socket for latest Intel
ϟ
Core
TM
Famil
/Pentium
®
/Celeron
®
Processors
2. DMIC Digital microphone header
3. SPEAKER Speaker header
4. F_AUDIO Front panel audio header
5. CLR_CMOS Clear CMOS jumper
6. PCIE1X Mini PCI Express x1 slot (supports half-card)
7. SATA1~2 Serial ATA 3.0 Gb/s connectors
8. ME_DISABLE ME disable jumper
9. LCD_SEL1~2 LCD select jumpers
10. HDD_PW HDD power connector
11. ODD_PW ODD power connector
12. F_USB1 Front panel USB 2.0 header
13. TS Touch board header
14. CAMERA CCD header
15. MCR Card reader header
16. F_PANEL Front panel switch/LED header
17. SYS_FAN 4-pin system cooling fan connector
18. CPU_FAN 4-pin CPU cooling fan connector
19. LCD_OFF Panel switch
20. LVDS LVDS header (optional)
21. DIMM1~2 204-pin DDR3 SO-DIMM sockets
22. FPD FPD power connector
1. CPU Socket
