9
Installing the Motherboard
Checking Jumper Settings
The following illustration shows the location of the motherboard jumpers. Pin 1 is
labeled.
Jumper Settings
Jumper
Type
Description Setting (default)
CLR_CMOS
3-pin
Clear CMOS
1-2: NORMAL
2-3: CLEAR
Before clearing the
CMOS, make sure to
turn off the system.
CLR_CMOS
ME_DISABLE
3-pin
Disable ME
1-2: ME ENABLE
2-3: ME DISABLE
ME_ENABLE
1
4-pin
SELECT LCD
0: BOE 23.6’’
HM236WU1-400
0: BOE 23.6’’
HM236WU1-400
LCD_SEL1
LCD_SEL2
LCD_SEL1
LCD_SEL2
1
4-pin
4: CMO 23.6’’
M236HGE-L20
SELECT LCD
4: CMO 23.6’’
M236HGE-L20
LCD_SEL1
LCD_SEL2
LCD_SEL1
LCD_SEL2
4-pin
2 & 4: BOE 21.5’
B3HT215F01-100
SELECT LCD
2 & 4: BOE 21.5’
B3HT215F01-100
LCD_SEL1
LCD_SEL2
4-pin
2-3: CPT 21.5’’
CLAA215FA04
SELECT LCD
2-3: CPT 21.5’’
CLAA215FA04
LCD_SEL1
LCD_SEL1
LCD_SEL2
LCD_SEL1
LCD_SEL2
LCD_SEL2
1
1
1
1
1
1
1
1
